Components
|
5" driver / coaxially mounted 1” dome tweeter
|
Max. sound pressure (1m, free field)1 with D6 / D12
|
116 / 117 dB SPL
|
Power handling capacity (RMS / peak 10 ms)
|
60 / 400 W
|
Frequency response (-5 dB)
|
85 / 1302 Hz - 20 kHz
|
Nominal dispersion angle (h x v)
|
100° conical
|
Cabinets per channel D6 / D12
|
4
|
|
|
Dimensions mm (H x W x D)
|
230 x 154 x 155
|
Weight kg
|
2.7
|
Dimensions inch (H x W x D)
|
9 x 6 x 6.1
|
Weight lb
|
6
|
